Integrate the OIDC protocol to OMS to implement SSO

Last Updated：2025-05-12 01:56:25 Updated

OceanBase Migration Service (OMS) must support the OpenID Connect (OIDC) protocol to adapt to the OAuth 2.0 authentication center. Currently, only the authorization-code grant type is supported. This topic describes the configurations to be updated to integrate the OIDC protocol into OMS to implement third-party single sign-on (SSO).

Obtain parameters from the authentication center

You must add your application to the third-party SSO service to obtain parameters required by OIDC, such as the application ID and key.

Parameter	Description
clientId	The client ID of the third-party application.
clientSecret	The client secret of the third-party application.
scope	The authorization scope. The value is a list of permission IDs separated with commas (,). `openid` must be included in the value, for example, `openid,profile`.
ClientAuthenticationMethod	The authentication method. Valid values: `client_secret_basic` (recommended) and `basic`.
jwk_set_uri	The endpoint used to retrieve the public key of the JSON web key (JWK) for decoding the JWK.
authorization_uri	The authorization endpoint.
token_uri	The endpoint used to obtain a token.

Configure a callback URL

If the third-party SSO system has a login callback URL allowlist, you must configure the allowlist.

Set the login callback URL to http://{serverDomain}/login/oauth2/code/oms, in which serverDomain is the domain name of the server where OMS is deployed.

Deploy OMS

This section describes how to log in to OMS deployed on a single node. If you want to deploy OMS on multiple nodes in a single region or on multiple nodes in multiple regions, see the "Deployment procedure with a configuration file" section in Deploy OMS on multiple nodes in a single region or Deploy OMS on multiple nodes in multiple regions.

Prerequisites

The installation environment meets the system and network requirements. For more information, see System and network requirements.
You have created a MetaDB cluster for OMS.
You have obtained the installation package of OMS, which is generally a tar.gz file whose name starts with oms.
You have loaded the installation package of OMS to the local image repository of the Docker container.

docker load -i <OMS installation package>
You have prepared a directory for mounting the OMS container. In the mount directory, OMS will create the /home/admin/logs, /home/ds/store, and /home/ds/run directories for storing the component information and logs generated during the running of OMS.
(Optional) You have prepared a time-series database for storing performance monitoring data and DDL/DML statistics of OMS.

Procedure

Log in to the server where OMS is to be deployed.
(Optional) Deploy a time-series database.

If you need to collect and display OMS monitoring data, deploy a time-series database. Otherwise, you can skip this step. For more information, see Deploy a time-series database.

Run the following command to obtain the deployment script docker_remote_deploy.sh from the loaded image:

sudo docker run --name oms-config-tool <OMS_IMAGE> bash && sudo docker cp oms-config-tool:/root/docker_remote_deploy.sh . && sudo docker rm -f oms-config-tool

deploy-1

Use the deployment script to start the deployment tool.
```
sh docker_remote_deploy.sh -o <Mount directory of the OMS container> -c <Directory of the existing config.yaml file> -i <IP address of the host> -d <OMS_IMAGE>
```
Note

For more information about settings of the config.yaml file, see the "Template and example of a configuration file" section.
Complete the deployment as prompted. After you set each parameter, press Enter to move on to the next parameter.
1. Select a deployment mode.

  Select Single Node in Single Region.
2. Select a task.

  Select Use Configuration File Uploaded with Script Option [-c].
3. If the system displays The specified database names already exist in the MetaDB. Are you sure that you want to continue?, it indicates that the database names you specified already exist in the MetaDB in the original configuration file. This may be caused by repeated deployment or upgrade of OMS. You can enter y and press Enter to proceed, or enter n and press Enter to modify the settings.
4. If the configuration file passes the check, all the settings are displayed. If the settings are correct, enter n and press Enter to proceed. Otherwise, enter y and press Enter to modify the settings.

  If the configuration file fails the check, modify the settings as prompted.
5. Specify the directory to which the OMS container is mounted on the node.

  Specify a directory with a large capacity.
6. Confirm whether the OMS image file can be named <OMS_IMAGE>.

  If yes, enter y and press Enter to proceed. Otherwise, enter n and press Enter to modify the settings.
7. Determine whether to mount an SSL certificate to the OMS container.

  If yes, enter y, press Enter, and specify the https_key and https_crt directories as prompted. Otherwise, enter n and press Enter.
8. Start the deployment.

To modify the configuration after deployment, perform the following steps:

Log in to the OMS container.
Modify the config.yaml file in the /home/admin/conf/ directory based on business needs.
Run the python -m omsflow.scripts.units.oms_init_manager --init-config-file command.
Run the supervisorctl restart oms_console oms_drc_supervisor command.

Template and example of a configuration file

Configuration file template

Notice

You must replace the sample values of required parameters based on your actual deployment environment. Both the required and optional parameters are described in the following table. You can specify the optional parameters as needed.
In the config.yaml file, you must specify the parameters in the key: value format, with a space after the colon (:).

# Information about the OMS MetaDB
oms_meta_host: ${oms_meta_host}
oms_meta_port: ${oms_meta_port}
oms_meta_user: ${oms_meta_user}
oms_meta_password: ${oms_meta_password}

# You can customize the names of the following three databases, which are created in the MetaDB when you deploy OMS.
drc_rm_db: ${drc_rm_db}
drc_cm_db: ${drc_cm_db}
drc_cm_heartbeat_db: ${drc_cm_heartbeat_db}

# Configurations of the OMS cluster
# In single-node deployment mode, the IP address of the server where OMS is to be deployed is used. We recommend that you use an internal IP address.
cm_url: ${cm_url}
cm_location: ${cm_location}
# The cm_region parameter is not required in single-node deployment mode.
# cm_region: ${cm_region}
# The cm_region_cn parameter is not required in single-node deployment mode.
# cm_region_cn: ${cm_region_cn}
cm_is_default: true
cm_nodes:
 - ${cm_nodes}

# Configurations of the time-series database
# The default value of `tsdb_enabled`, which specifies whether to configure a time-series database, is `false`. To enable metric reporting, set the parameter to `true`.
# tsdb_enabled: false
# If the `tsdb_enabled` parameter is set to `true`, delete comments for the following parameters and specify the values based on your actual configurations.
# tsdb_service: 'INFLUXDB'
# tsdb_url: '${tsdb_url}'
# tsdb_username: ${tsdb_user}
# tsdb_password: ${tsdb_password}

# The following table describes the parameters that need to be added when you log in to OMS by using SSO.
oms_iam_auth: OAUTH2
oms_oauth2_user_account_name_field: nickname
oms_oauth2_sso_login_url: http://oms.example/org:8090/omsp/oauth2/authorization/oms?oms_back_url=http://oms.example.org:8090
spring_security_oauth2_client_registration_oms_client_id: xxx
spring_security_oauth2_client_registration_oms_client_secret: xxx
spring_security_oauth2_client_registration_oms_redirect_uri: http://oms.example.org:8090/omsp/login/oauth2/code/{registrationId}
spring_security_oauth2_client_registration_oms_authorization_grant_type: authorization_code
spring_security_oauth2_client_registration_oms_scope: openid,profile
spring_security_oauth2_client_registration_oms_clientAuthenticationMethod: client_secret_basic
spring_security_oauth2_client_registration_oms_provider: oms
spring_security_oauth2_client_provider_jwk_set_uri: https:xxx.com
spring_security_oauth2_client_provider_authorization_uri: https://xxxx/api/auth
spring_security_oauth2_client_provider_token_uri: https://xxx/api/token

Parameter	Description	Required?
oms_meta_host	The IP address of the MetaDB, which can only be the IP address of a MySQL-compatible tenant of OceanBase Database V2.0 or later.	Yes
oms_meta_port	The port number of the MetaDB.	Yes
oms_meta_user	The username of the MetaDB.	Yes
oms_meta_password	The user password of the MetaDB.	Yes
drc_rm_db	The name of the database for the OMS console.	Yes
drc_cm_db	The name of the MetaDB for the CM service.	Yes
drc_cm_heartbeat_db	The name of the heartbeat database for the CM service.	Yes
cm_url	The URL of the OMS CM service, for example, `http://xxx.xxx.xxx.xxx:8088`. Note In single-node deployment mode, the IP address of the server where OMS is to be deployed is used. We recommend that you do not set it to `http://127.0.0.1:8088`. The access URL of the OMS console is in the following format: `IP address of the host where OMS is deployed:8089`, for example, `http://xxx.xxx.xxx.xxx:8089` or `https://xxx.xxx.xxx.xxx:8089`. Port 8088 is used for program calls, and Port 8089 is used for web page access. You must specify port 8088.	Yes
cm_location	The code of the region. Value range: [0,127]. You can select one number for each region.	Yes
cm_region	The name of the region, for example, cn-jiangsu. Notice If you use OMS with the Alibaba Cloud Multi-Site High Availability (MSHA) service in an active-active disaster recovery scenario, use the region configured for the Alibaba Cloud service.	No
cm_region_cn	The value here is the same as the value of cm_region.	No
cm_nodes	The IP addresses of servers on which the OMS CM service is deployed.	Yes
cm_is_default	Specifies whether the CM service is enabled for OMS by default.	No. Default value: `true`.
tsdb_enabled	Specifies whether metric reporting is enabled for monitoring. Valid values: `true` and `false`.	No. Default value: `false`.
tsdb_service	The type of the time-series database. Valid values: `INFLUXDB` and `CERESDB`.	No. Default value: `INFLUXDB`.
tsdb_url	The IP address of the server where InfluxDB is deployed. You need to modify this parameter based on the actual environment if you set the `tsdb_enabled` parameter to `true`.	No
tsdb_username	The username used to connect to the time-series database. You need to modify this parameter based on the actual environment if you set the `tsdb_enabled` parameter to `true`. After you deploy a time-series database, manually create a user and specify the username and password.	No
tsdb_password	The password used to connect to the time-series database. You need to modify this parameter based on the actual environment if you set the `tsdb_enabled` parameter to `true`.	No
oms_iam_auth	The login method. Valid values: `OAUTH2` and `LOCAL`. `OAUTH2` is compatible with the password-based login method.	Yes
oms_oauth2_user_account_name_field	The field used to obtain the username from IdToken. Example: `nick` or `nickname`.	Yes
oms_oauth2_sso_login_url	The redirection URL for SSO based on the OIDC protocol. The value is in the format of `http://{serverDomain}/omsp/oauth2/authorization/oms?oms_back_url={serverDomain}`. {serverDomain} is the domain name and `oms_back_url` is the page of OMS displayed after the login succeeds.	Yes
spring_security_oauth2_client_registration_oms_client_id	The client ID of the third-party application.	Yes
spring_security_oauth2_client_registration_oms_client_secret	The client secret of the third-party application.	Yes
spring_security_oauth2_client_registration_oms_redirect_uri	The callback URL in the `http://{serverDomain}/login/oauth2/code/{registrationId}` format, which is specified by `redirectUrl`. {serverDomain} is the domain name and {registrationId} does not need to be specified.	Yes
spring_security_oauth2_client_registration_oms_authorization_grant_type	The grant type used by OMS to obtain access tokens from the OAuth2 authorization server. Currently, only the `authorization-code` grant type is supported.	Yes
spring_security_oauth2_client_registration_oms_scope	The authorization scope. The value is a list of permission IDs separated with commas (,). `openid` must be included in the value.	Yes
spring_security_oauth2_client_registration_oms_provider	The name of the authorization service provider. You can define the value. Example: oidc.	Yes
spring_security_oauth2_client_provider_jwk_set_uri	The endpoint used to retrieve the public key of the JSON web key (JWK) for decoding the JWK.	Yes
spring_security_oauth2_client_provider_authorization_uri	The authorization endpoint.	Yes
spring_security_oauth2_client_provider_token_uri	The endpoint used to obtain a token.	Yes

Sample configuration file

Replace related parameters with the actual values in the target deployment environment.

oms_meta_host: xxx.xxx.xxx.xxx
oms_meta_port: 2883
oms_meta_user: oms_meta_user
oms_meta_password: ***********
drc_rm_db: oms_rm
drc_cm_db: oms_cm
drc_cm_heartbeat_db: oms_cm_heartbeat
cm_url: http://xxx.xxx.xxx.xxx:8088
cm_location: 100
cm_region: cn-anhui
cm_region_cn: cn-anhui
cm_is_default: true
cm_nodes:
  - xxx.xxx.xxx.xxx
tsdb_service: 'INFLUXDB'
tsdb_enabled: true
tsdb_url: 'xxx.xxx.xxx.xxx:8086'
tsdb_username: username
tsdb_password: *************
oms_iam_auth: OAUTH2
oms_oauth2_user_account_name_field: nickname
oms_oauth2_sso_login_url: http://oms.example/org:8090/omsp/oauth2/authorization/oms?oms_back_url=http://oms.example.org:8090
spring_security_oauth2_client_registration_oms_client_id: xxx
spring_security_oauth2_client_registration_oms_client_secret: xxx
spring_security_oauth2_client_registration_oms_redirect_uri: http://oms.example.org:8090/omsp/login/oauth2/code/{registrationId}
spring_security_oauth2_client_registration_oms_authorization_grant_type: authorization_code
spring_security_oauth2_client_registration_oms_scope: openid,profile
spring_security_oauth2_client_registration_oms_clientAuthenticationMethod: client_secret_basic
spring_security_oauth2_client_registration_oms_provider: oms
spring_security_oauth2_client_provider_jwk_set_uri: https:xxx.com
spring_security_oauth2_client_provider_authorization_uri: https://xxxx/api/auth
spring_security_oauth2_client_provider_token_uri: https://xxx/api/token
